HV3584T-WHT - Barline Aluminium White 1000mm Wall Light

• Barline LED Wall Light
• Aluminium Poly Powder Coated White
• High Grade  UV Stabilised Perspex Diffuser
• IP rating: IP65
• Input voltage: Available in either 240v or 24v DC
• TRI Colour - 3000k, 4000k, 5500k
• Built-in 15w-30w LED  (3000k = 15w | 4000k = 30w | 5500k = 15w)
• 3 years replacement warranty (items ordered after 01/01/22)

24v DC Model must be used with suitable 24V DC LED driver - View Here

Product Information

Part Number	Colour Temp	Lumens	Included LED	Input Voltage
HV3584T-WHT	3000k 4000k 5500k	900lm 1800lm 975lm	15w-30w 240v Built in LED	240v
HV3584T-WHT-24V	3000k 4000k 5500k	900lm 1800lm 975lm	15w-30w 24v DC Built in LED	24v DC

Data Sheet

Data Sheet

IES Files

IES Files

Install Sheet

240v Installation Instructions

24v DC Installation Instructions
