HV9661-100W - 100W Triac + 0-1/10v Dimmable LED Driver

Product image 1
Product image 2
Product image 3
Product image 4

HV9661-100W - 100W Triac + 0-1/10v Dimmable LED Driver

  • 2in1 Dimmable LED Driver
  • TRIAC + 0-1/10v
  • Dimmable using either Trailing or Leading Edge Dimmers
  • Dimmable using 0-1/10v
  • High Power Factor 0.95
  • Flex and Plug Included
  • IP rating: IP66
  • Input Voltage: 240v AC
  • Output Power: 100w
  • Recommended Maximum load: 80w
  • Recommended Minimum Load: 10w
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
Product Information
Part Number Output Voltage
HV9661-12V100W 12v DC Constant Voltage
HV9661-24V100W 24v DC Constant Voltage
Data Sheet

Data Sheet

Install Sheet

Installation Instructions

Select PART NUMBER
From $41.78

Original: $119.36

-65%
HV9661-100W - 100W Triac + 0-1/10v Dimmable LED Driver—

$119.36

$41.78

Product Information

Shipping & Returns

Description

  • 2in1 Dimmable LED Driver
  • TRIAC + 0-1/10v
  • Dimmable using either Trailing or Leading Edge Dimmers
  • Dimmable using 0-1/10v
  • High Power Factor 0.95
  • Flex and Plug Included
  • IP rating: IP66
  • Input Voltage: 240v AC
  • Output Power: 100w
  • Recommended Maximum load: 80w
  • Recommended Minimum Load: 10w
  • 3 Years Replacement Warranty (items ordered after 01/01/22)
Product Information
Part Number Output Voltage
HV9661-12V100W 12v DC Constant Voltage
HV9661-24V100W 24v DC Constant Voltage
Data Sheet

Data Sheet

Install Sheet

Installation Instructions
